Description:

Specifications:

Engine:

• Bar: 24" RSN
• Pitch: 3/8"
• Chain Type: C83
• Chain Speed at Max Power: 75.5 ft/s
• Cylinder Displacement: 5.25 cu.in
• Output Shaft Power: 6.9 hp

Dimensions:

• Weight (excluding cutting equipment): 16.5 lbs

Equipment:

• Recommended Bar Length (Min): 18 in
• Recommended Bar Length (Max): 36 in
• Bar Length: 60 cm / 24 in

Emission:

• Exhaust Emissions (CO₂ EU V): 792 g/kWh

Vibration:

• Front Handle Vibration Level (ahv, eq): 6.7 m/s²
• Rear Handle Vibration Level (ahv, eq): 5.9 m/s²

Sound and Noise:

• Sound Pressure Level at Operator’s Ear: 112 dB(A)
• Guaranteed Sound Power Level (LWA): 119 dB(A)

Width	Weight	Height	Length
	16.5 Pounds		0 Inch
