Description:

Specifications:

Engine & Performance:

• Engine displacement: 70.7 cm³
• Output shaft power: 4.9 hp
• Torque (max): 3.8 Nm at 6,600 rpm
• Chain speed at max power: 74.5 ft/s
• Maximum power speed: 10,200 rpm
• Clutch engagement speed (±120): 3,500 rpm
• Idling speed: 2,700 rpm
• Electrode gap: 0.02 in
• Ignition module air gap: 0.01 in
• Spark plug: Champion RCJ7Y, NGK BPMR7A

Cutting Equipment:

• Bar type: RSN (Replaceable Sprocket Nose)
• Bar length: 20 inches (50 cm)
• Pitch: 3/8"
• Gauge: .058"
• Chain type: H42
• Sprocket type: Rim 7
• Recommended bar length: 16 – 28 in

Oil & Lubrication:

• Oil pump type: Adjustable flow, no flow at idle
• Oil pump capacity: 4 – 20 ml/min
• Oil tank volume: 0.89 US pint
• Lubricant: Husqvarna 2-stroke or equivalent at 50:1 mix

Dimensions & Weight:

• Weight (excluding cutting equipment): 14.1 lbs

Sound and Noise:

• Sound pressure level at operator’s ear: 110 dB(A)
• Guaranteed sound power level (LWA): 119 dB(A)
• Measured sound power level: 118 dB(A)

Vibration Levels:

• Front handle: 5.7 m/s²
• Rear handle: 8.0 m/s²

Emissions:

• CO₂ emissions (EU V standard): 747 g/kWh

Width	Weight	Height	Length
	14.1 Pounds		0 Inch
